3-Year WarrantyDependable and uncomplicated engine-driven welder ideal for Stick and Flux-Cored welding applications. The Bobcat 230 is purpose-built to cater to maintenance and repair tasks, construction projects, farm and ranch operations, and serve as a reliable source of auxiliary power.
The single-knob design simplifies the process, allowing for quick and precise adjustment and monitoring of amperage and voltage. This user-friendly feature facilitates the attainment of accurate weld parameters with ease.
Unmatched welding performance with 7018 and 6010 stick electrodes. These electrodes offer effortless arc initiation and produce minimal spatter, resulting in increased productivity to meet your welding needs.
Experience uninterrupted full auxiliary power, free from arc interference, ensuring superior weld quality. Your job site tools can operate seamlessly, allowing you to accomplish more without interruptions.
Enhance your mobility and conserve truck space and payload capacity with a design that is more than 100 pounds lighter and 13 percent smaller than the previous model.
Simplify your maintenance routine with the user-friendly design of our Bobcat engine-driven welder. Daily upkeep becomes a quick and straightforward task.
Try these accessories with your new Bobcat™ 230 Engine-Driven Welder:
+
+
+
| Bobcat™ 230 (Kohler) - Specifications | |
|---|---|
| Industries Interests | Farm and Ranch Work Truck Construction and Fabrication |
| Amperage | 20 A - 230 A |
| Weldable Metals | Stainless Steel Steel |
| Current Type | DC |
| Portability | Lift Eye (Standard) Running Gear / Cart (Optional) Trailer (Optional) |
| Engine Brand | Kohler |
| Engine Idle Speed | 2300 RPM |
| Engine Weld Speed | 3600 |
| Fuel Tank Size | 11 Gallon |
| Fuel Type | Gasoline |
| Horsepower | 23.5 hp |
| Weld Output | CC / CV |
| Rated Output | CC/DC Stick 230 A at 29.2 V, 100% duty cycle, CV/DC MIG/FCAW 230 A at 25.5 V, 100% duty cycle |
| Single Phase Auxiliary Continuous Power | 9500 W |
| Single Phase Auxiliary Peak Power | 11000 W |
| Sound Rating | 64 dB @ idle and 73 dB @ weld |
| Applications | Fabrication Industrial Welding Mobile Fabrication & MRO |
| Net Width | 20.13 in |
| Net Height | 26.5 in |
| Net Length | 37.06 in |
| Net Weight | 382 lbs |
| Warranty | Miller's True Blue Warranty |
SHIPPING DIMENSIONS |
|
| Height: | 26.50 Inches |
| Width: | 20.13 Inches |
| Length: | 37.06 Inches |
| Weight: | 382 Lb(s) 0 Oz |
