Razorweld RazorArc 200di Stick/TIG Welder #JRW200di
Part Number:
JRW200di
Razorweld RazorArc 200di Stick/TIG Welder #JRW200di
Part Number:
JRW200di

The RAZORARC 200di is a compact yet powerful Stick and Lift TIG welder designed for performance, reliability, and portability. With an intelligent synergic control system, ClearVision technology, and Smart Lift TIG, it offers advanced welding capabilities in a rugged 16 lb package. Packed with features like adjustable hot start and arc force, generator compatibility, and wireless remote readiness, it’s built to handle demanding industrial environments with ease.
RAZORARC 200di Specifications | |
---|---|
Input Power | AC 95–265V, 50/60Hz |
Open Circuit Voltage | 78V |
ARC Output Range (115V / 230V) | 20–120A / 20–200A |
ARC Duty Cycle | 25% |
TIG Output Range (115V / 230V) | 10–160A / 10–200A |
TIG Duty Cycle | 25% |
Efficiency | 85% |
Power Factor | 0.99 |
Idle State Power | ARC: 46.8W, TIG: 7W |
Protection Class | IP23S |
Insulation Class | H |
Dimensions (L x W x H) | 16" x 6" x 12" |
Net Weight | 16 lbs |
SHIPPING DIMENSIONS |
|
Height: | 12.00 Inches |
Width: | 6.00 Inches |
Length: | 16.00 Inches |
Weight: | 16 Lb(s) 0 Oz |
