Razorweld RazorArc 200di Stick/TIG Welder #JRW200di

Part Number: JRW200di

Ships Free To Lower 48 States

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di

Welder using the Razorweld RazorArc 200di Stick/TIG Welder #JRW200di

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di for sale at Welders

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di foot pedal

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di spool gun

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di stick welding

Razorweld RazorArc 200di Stick/TIG Welder #JRW200di

Part Number: JRW200di

Features
Specs
Documents
Videos
Consumables
FAQS

RazorArc 200di #JRW200di

The RAZORARC 200di is a compact yet powerful Stick and Lift TIG welder designed for performance, reliability, and portability. With an intelligent synergic control system, ClearVision technology, and Smart Lift TIG, it offers advanced welding capabilities in a rugged 16 lb package. Packed with features like adjustable hot start and arc force, generator compatibility, and wireless remote readiness, it’s built to handle demanding industrial environments with ease.

Highlights

Portable Performance: Weighs only 16 lbs yet delivers up to 200A output—perfect for shop or field work
Smart Lift TIG & Stick Modes: Supports Lift TIG and ARC welding with precise output and arc stability
ClearVision Technology: Enhanced arc visibility for more control and weld quality
Synergic Control: Intelligent arc control adjusts for optimal performance across varying conditions
Rugged Industrial Build: Ergonomic, durable design built to withstand tough environments
Adjustable Arc Dynamics: Fine-tune arc start, anti-stick, and arc force for specific electrode and material requirements
Wide Voltage Compatibility: Operates on 95–265V AC input with auto-detection for flexible use with generators
Advanced Safety Features: Includes VRD, overcurrent/overheat protection, and electronic component safeguards
Wireless Remote Ready: Compatible with optional wireless remotes and receiver module for added convenience
Active Cooling Technology: ABAP system with on-demand fan helps regulate internal temperature efficiently

What's Included:

RAZORARC 200di Welder
Arc Lead Set
Ground Cable
Power Adaptor
Operating Manual

RAZORARC 200di Specifications
Input Power	AC 95–265V, 50/60Hz
Open Circuit Voltage	78V
ARC Output Range (115V / 230V)	20–120A / 20–200A
ARC Duty Cycle	25%
TIG Output Range (115V / 230V)	10–160A / 10–200A
TIG Duty Cycle	25%
Efficiency	85%
Power Factor	0.99
Idle State Power	ARC: 46.8W, TIG: 7W
Protection Class	IP23S
Insulation Class	H
Dimensions (L x W x H)	16" x 6" x 12"
Net Weight	16 lbs
