Razorweld RazorTig 200Pdi Tig/Stick Welder - JRW200Pdi
Part Number:
JRW200Pdi
Razorweld RazorTig 200Pdi Tig/Stick Welder - JRW200Pdi
Part Number:
JRW200Pdi

Razorweld
Welding type:

TIG

The RAZORTIG 200Pdi is a high-performance AC/DC TIG and Stick welder designed for serious fabricators and professionals. With advanced pulse TIG controls, Smart Lift and HF TIG starting, and both AC and DC output capabilities, it offers precision and versatility for aluminum, stainless steel, and mild steel welding. Compact, lightweight, and generator-ready, the 200Pdi is built with safety features and pro-grade customization in a rugged ergonomic design.
RAZORTIG 200Pdi Specifications | |
---|---|
Input Power | AC 95–265V, 50/60 Hz |
Open Circuit Voltage | 68V |
TIG Output Range | 5–160A (115V), 5–200A (230V) |
TIG Rated Duty Cycle | 25% |
Stick Output Range | 10–120A (115V), 10–180A (230V) |
Stick Rated Duty Cycle | 25% |
Efficiency | 84% |
Power Factor | 0.99 |
Idle State Power | 33W (MMA/STICK/TIG), 7W (TIG) |
Protection Class | IP23S |
Insulation Class | H |
Dimensions (L x W x H) | 18" x 6" x 12.5" |
Net Weight | 20 lbs |
SHIPPING DIMENSIONS |
|
Height: | 12.50 Inches |
Width: | 6.00 Inches |
Length: | 18.00 Inches |
Weight: | 20 Lb(s) 0 Oz |
