| POWER MIG® 215 MPi™ Multi-Process Welder Aluminum One-Pak - Specifications |
| Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) |
120/1/60 |
| Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) |
MIG: 105A/19.25V/40% 80A/18V/100% |
| Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) |
TIG: 130A/15.2V/40% 100A/14V/100% |
| Phase 1: Rated Output #1C (Current/Voltage/Duty Cycle) |
Stick: 85A/23.4V/40% 60A/22.4V/100% |
| Phase 1: Input Current at Max Rated Output #1 (Current) |
22A |
| Phase 1: Input Voltage #2 (Voltage/Phase/Hertz) |
230/1/60 |
| Phase 1: Rated Output #2A (Current/Voltage/Duty Cycle) |
MIG: 215A/24.8V/30% 120A/20V/100% |
| Phase 1: Rated Output #2B (Current/Voltage/Duty Cycle) |
TIG: 175A/17V/30% 110A/14.4V/100% |
| Phase 1: Rated Output #2C (Current/Voltage/Duty Cycle) |
Stick: 175A/27V/30% 110A/24.4V/100% |
| Phase 1: Input Current at MAX Rated Output #2 (Current) |
29A |
| Machines Processes |
Stick (SMAW) Flux-Cored (FCAW) TIG (GTAW) MIG (GMAW) |
| IEC Rating |
IP21S |
| Max Rating |
220A |
| Output Range by Mode |
MIG: 20-220A |
| Number of Operators per Machine |
1 |
| Machines Communication Technology |
digital |
| Work Lead Connector Type |
Dinse |
| Welding Gun Cable Assembly Length |
Magnum PRO 175L |
| Work Cable Length |
10 FT |
| Spool Gun Compatible (Duty) |
Light |
| Wire and TIG Feeders |
| UI type |
TFT - Graphic |
| Wire Feeders Processes |
MIG |
| Flux Cored |
| Contact Tips Included |
Yes |
| Maximum Wire Thickness |
0.045 in (1.1 mm) |
| Minimum Wire Thickness |
0.025 in (0.6 mm) |
| Sample MIG Wire Included |
Yes |
| Input Voltage |
120/230 |
| Input Current |
120V: 15A, 230V: 15.9A |
| Input Hertz |
60 |
| Input Power |
120/230/1/60 |
| Input Phase |
1 |
| Mode Icon |
CC/CV |
| Output Range |
120V: 20-140A DC 230V: 20-220A DC Max. OCV: 56V |
| Polarity |
DC |
| Rated Output |
120V: 105A/19.3/40% 230V: 215A/24.8V/30% |
| Typical Application |
Automotive Brewery Distillery General Fabrication Maintenance & Repair Repair Welding |
| Warranty |
3 Years |
