Miller® D-74D Dual Wire Feeder 300620

Part Number: 300620
UPC: 715959419215

Miller® D-74D Dual Wire Feeder 300620

Part Number: 300620
UPC: 715959419215
Out of Stock

Related Products

  • 24 VAC, 10 A & 50/60 Hz Input Powers
  • Lightweight & Portable
  • Multiprocess Compatible
  • 3-Year Power Warranty

Miller® D-74D Dual Wire Feeder 300620 For .023" - 1/8" Carbon Steel Wire

Do not worry about changing wire spools to alternate between two wires anymore. The Miller dual wire feeder allows you to change wires quickly and easily. The rotatable drive assembly allows for the rotation of the housing. Severe bends are reduced in the wire feed, prolonging the life of the gun liner and the gun itself.

Posifeed™ wire drive quickly surpasses wire feed competitors. Performance is enhanced by positive wire feeding. A calibrated drive roll-pressure arm provides quick and easy drive roll changes. Solid-state speed control removes the necessity for electrical relays and makes this machine more durable. All Miller guns will attach with quick connect.

This Miller wire feeder is equipped to handle MIG and Flux-Core welding. Equipped with a trigger hold, the D-74D allows welders in making longer welds. Arc starts are improved with automatic run-in control.

Features:

  • Wire Feed Speed ranges between 50 and 780 ipm
  • Wire Diameter Capacity of .6 mm to 2.0 mm
  • Compatible with input powers: 24 VAC, 10 A, and 50/60 Hz
  • 24 VDC high-torque, permanent-magnet motor
  • Standard 10 ft 14-pin interconnecting cord is included

This is the perfect tool for any work location. It is the perfect fit for repeating welds or a variety of projects. Miller D-74D Dual Wire Feeder can maneuver with a wire-feeding arm assembly. Also, this feeder can store four independent welder parameters to reduce setup time.

Applications:

  1. Heavy manufacturing
  2. Light manufacturing
  3. Metal fabrication
  4. Construction

FREE SHIPPING ON ORDERS OVER $300

All purchases over $300 qualify for free shipping anywhere within the continental U.S. Count on Welders Supply for the best equipment, the best prices, and free shipping.



View our other Wire Feeders for more selection.

Processes:

  • MIG (GMAW)
  • Flux Cored (FCAW)
  • Pulsed MIG (GMAW) with MPa Plus feeder and optional MPa power source

Input Power Wire Diameter Capacity Wire Feed Speed Weight Height Width Depth
24 VAC, 10 A, 50/60 Hz .023 - 5/64" (.6 - 2mm) 50-780 IPM (1.3 - 19.8 m/min.) Dual Feeder, 87 lb / 39.5 kg 14"/356mm 21" / 533mm 35"/889mm







SHIPPING DIMENSIONS

Height: 15.06 Inches
Width: 21.02 Inches
Length: 37.06 Inches
Weight: 90 Lb(s) 0 Oz

Product Questions and Answers


Q - How fast does it feed wire? A - 50 to 780 IPM
Q - What size wire can it handle: A - .023 to 5/64"
