Lincoln Electric POWER MIG® 215 MPi™ Multi-Process Welder, TIG One-Pak® #K4878-1
Lincoln Electric POWER MIG® 215 MPi™ Multi-Process Welder, TIG One-Pak® #K4878-1
Ships Free To Lower 48 States
Welding type:
MIG
TIG
Ships Free To Lower 48 States

Lincoln Electric designed and built the Power MIG 215 MPi to be one of the highest-quality machines in its class on the market. It is easy to use, reliable, and powerful. It has MIG, TIG, stick, and flux-cored welding capabilities and comes with loads of exclusive features. The sleek and solid ergonomic design with multiple lift points maximizes mobility around the shop, and user-friendly technology makes the setup process and selection of weld settings incredibly simple. Take on any job – MIG, TIG, Stick or Flux-Cored – with the versatile POWER MIG 215 MPi welder. It has a sleek and rugged design for increased portability and comes with a 3-year warranty. Make your next project a breeze with the Power MIG 215 MPi. It is commonly used for automotive, brewery, and repair applications.
Features of the POWER MIG® 215 MPi™
30-Day Submission Deadline
Rebate claims must be submitted within 30 days of purchase date.
| POWER MIG® 215 MPi™ Multi-Process Welder Aluminum One-Pak® - Specifications | |
|---|---|
| Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) | 120/1/60 |
| Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) | MIG: 105A/19.25V/40% 80A/18V/100% |
| Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) | TIG: 130A/15.2V/40% 100A/14V/100% |
| Phase 1: Rated Output #1C (Current/Voltage/Duty Cycle) | Stick: 85A/23.4V/40% 60A/22.4V/100% |
| Phase 1: Input Current at Max Rated Ouput #1 (Current) | 22A |
| Phase 1: Input Voltage #2 (Voltage/Phase/Hertz) | 230/1/60 |
| Phase 1: Rated Output #2A (Current/Voltage/Duty Cycle) | MIG: 215A/24.8V/30% 120A/20V/100% |
| Phase 1: Rated Output #2B (Current/Voltage/Duty Cycle) | TIG: 175A/17V/30% 110A/14.4V/100% |
| Phase 1: Rated Output #2C (Current/Voltage/Duty Cycle) | Stick: 175A/27V/30% 110A/24.4V/100% |
| Phase 1: Input Current at MAX Rated Output #2 (Current) | 29A |
| Machines Processes | Stick (SMAW) Flux-Cored (FCAW) TIG (GTAW) MIG (GMAW)  |
| IEC Rating | IP21S |
| Max Rating | 220A |
| Output Range by Mode | MIG: 20-220A |
| Number of Operators per Machine | 1 |
| Machines Communication Technology | digital |
| Work Lead Connector Type | Dinse |
| Welding Gun Cable Assembly Length | Magnum PRO 175L |
| Work Cable Length | 10 FT |
| Spool Gun Compatible (Duty) | Light |
| Wire and TIG Feeders | |
| UI type | TFT - Graphic |
| Wire Feeders Processes | MIG |
| Flux Cored | |
| Contact Tips Included | Yes |
| Maximum Wire Thickness | 0.045 in (1.1 mm) |
| Minimum Wire Thickness | 0.025 in (0.6 mm) |
| Sample MIG Wire Included | Yes |
| Input Voltage | 120/230 |
| Input Current | 120V: 15A, 230V: 15.9A |
| Input Hertz | 60 |
| Input Power | 120/230/1/60 |
| Input Phase | 1 |
| Mode Icon | CC/CV |
| Output Range | 120V: 20-140A DC 230V: 20-220A DC Max. OCV : 56V |
| Polarity | DC |
| Rated Output | 120V: 105A/19.3/40% 230V: 215A/24.8V/30% |
| Typical Application | Automotive Brewery Distillery General Fabrication Maintenance & Repair Repair Welding  |
| Warranty | 3 Years |
SHIPPING DIMENSIONS |
|
| Height: | 15.08 Inches |
| Width: | 10.88 Inches |
| Length: | 23.14 Inches |
| Weight: | 48 Lb(s) 0 Oz |
