Miller Continuum™ 500 MIGRunner Pkg 951672
Part Number: 951672
Welding type:
MIG
Power supply:
220V 3 Phase
460V
Material type:
Mild Steel
Stainless Steel
Documents
Videos
MIG Welding
3-Phase
Multi-Voltage
3-Year Miller Warranty
Miller Continuum™ 500 MIGRunner Pkg 951672
The newest generation of industrial welders features superior weld quality, ease of use, and system flexibility.
Features:
- All-new power source design
- All-new feeder design
- Superior Arc Performance
- Balanced-pressure drive-roll design and tensioners
- Easy to set up and adjust with minimal training
- Tool-less lockable rotatable drive
- LCD Display
- Adaptable to a variety of weld cell configurations
View our full selection of Mig, Tig, Stick and Gas welders available online. Also, view our plasma cutting machines and other welding tools.
Other Versions of the Miller Continuum™ 500:
Miller Continuum™ 500 MIGRunner Pkg #951672 Specifications: | |
|---|---|
| Input Voltage Options | Auto-Line™ 230–575 V, 3-phase, 50/60 Hz |
| Rated Output |
350 A at 100% duty cycle |
| Welding Output Range | 20–400 A 10–44 V |
| Max Open Circuit Voltage | 75 VDC |
| Processes | Advanced MIG processes: – Accu-Pulse® pulsed MIG (GMAW-P) – Versa-Pulse™ – RMD® – MIG (GMAW) – High-deposition MIG (GMAW) Flux-cored (FCAW) Air carbon arc (CAC-A) (Rated for 1/4-inch carbons) |
| Industrial Applications | Construction equipment Automotive components Recreational vehicles Farm machinery Office furniture Mining machinery Industrial fabrication |
| Weldable Metals | Steel Stainless Steel |
| Portability | Running Gear / Cart (Standard) |
| Net Width | 17.5 in. (444 mm) |
| Net Height | 27.19 in. (691 mm, including lift eye) |
| Net Length | 28.13 in. (714 mm) |
| Net Weight | 127 lb. (57.6 kg) |
| Warranty | 3 Years - Miller's True Blue Warranty |
Miller Continuum™ 500 Wire Feeder Specifications: | |
|---|---|
| Input Power | 50 VDC |
| Input Welding Circuit Rating | 500 A at 100% duty cycle |
| Wire Feed Speed | 50–1,000 ipm (1.27–25.4 m/min.) |
| Wire Diameter Capacity | .035–5/64 in. (0.9–2.0 mm) |
| Maximum Spool Size Capacity | 18 in. (457 mm) 60 lb. (27 kg) |
| Net Width | 16.31 in. (414 mm) |
| Net Height | 13.81 in. (351 mm) |
| Net Length | 29.69 in. (754 mm) |
| Net Weight | 43 lb. (19.5 kg) |
SHIPPING DIMENSIONS |
|
| Height: | 42.00 Inches |
| Width: | 32.00 Inches |
| Length: | 52.00 Inches |
| Weight: | 370 Lb(s) 0 Oz |
Consumables
Product Questions and Answers
Q - What is the free helmet this comes with?
A - The Miller Classic Series Auto Darkening Welding Helmet Black Variable Shade, Part #251292
Q - What size generator is needed to run the Continuum 500 MIGRunner?
A - Minimum 25KW
