Millermatic 190 Auto-Set 220 Volt Wire Welder Part#907613 DISCONTINUED

Part Number: 907613
This Item Has Been Discontinued and has been replaced by Millermatic 211 Autoset Mig Welder #907614 - Level up today!

Welding type:

MIG

MIG

Power supply:

220V Single Phase

220V Single Phase

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

  • MIG Welding
  • 220V
  • Single Phase
  • 3-Year True Blue Warranty

Millermatic 190 Auto-Set Wire Welder #907613 (DISCONTINUED)

FREE SHIPPING TO THE LOWER 48 States.

The Millermatic 190 Auto-Set is the entry level 220 volt wire welder anyone and everyone can set. It features Auto Set wire welder for great results. Auto Set automatically sets your welding machine to the proper parameters - hassle-free with no more guesswork. Welds the thickest material in its class, up to 5/16 in. during a single pass.

Smooth-Start - This is the best starting machine in the MIG category. Complete your jobs smooth and spatter-free. No more pop-gun starts or spatter to clean up.

Spool Gun Compatible - Weld from 18 gauge to 1/4 in. aluminum using the Miller Spoolmate 100 spool gun hooked up to a 100 auto-set.

Thermal Overload Protection - If the duty cycle is exceeded or the airflow is blocked it will automatically deactivate the unit turn on the over temperature light. Conveniently it automatically resets once the fault is corrected or the unit is cooled.

New Angled Durable Cast Aluminum Drive System - incorporates dual groove quick-change drive roll and spring-loaded tension arm with calibrated tension knob to make your setup quicker and easier. Angled drive for an easier feed and longer liner life.

“Tip Saver” Short Circuit Protection – Extend the life of your contact tips and protect internal components from damage. Automatically shuts down when tip is shorted to the work.

Aluminum Welding Applications

  • Farm and Ranch
  • Field Maintenance and Repair
  • Home/Hobby
  • Mechanical Contracting
  • Metal Art/Sculpture
  • Motorsports (car, truck, bike, etc.)
  • Schools/Training
  • Welding Projects

This is a top of the line Miller welding machine guaranteed to be a good fit in your welding shop!

Be sure to view Welders Supply Company’s full selection of Mig, Tig, Stick and Gas welders available at the best prices online!

Specifications

Input Power Requires 1-Phase power
240 V, 21 A, 60 Hz
Rated Output 140 Amps at 21 VDC, 40% Duty Cycle
Welding Amperage Range 30 - 190 Amps
Wire Speed 60 - 600 IPM (.4 - 9 m/min)
Net Weight 35 lb (15.90 kg)
WireDiameter Capacity .024 - .035 in (0.6 - 0.9 mm) Solid Steel
.024 - .035 in (0.6 - 0.9 mm) Stainless
.030 - .045 in (0.8 - 1.2 mm) Flux Cored
MaxSpoolSize Capacity 8 in (203 mm)

SHIPPING DIMENSIONS

Height: 11.00 Inches
Width: 13.00 Inches
Length: 21.00 Inches
Weight: 50 Lb(s) 0 Oz
