| Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) |
120/1/60 |
| Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) |
MIG 95A/18.8/60% 75A/17.8V/100% |
| Phase 1: Input Current at Max Rated Ouput #1 (Current) |
20A |
| Phase 1: Input Voltage #2 (Voltage/Phase/Hertz) |
230/1/60 |
| Phase 1: Rated Output #2A (Current/Voltage/Duty Cycle) |
MIG 175A/22.8V/30% 90A/18.6V/100% |
| Phase 1: Input Current at MAX Rated Output #2 (Current) |
22.5A |
| IEC Rating |
IP21S |
| Max Rating |
211A |
| Output Range by Mode |
MIG: 20-211A |
| Number of Operators per Machine |
1 |
| Machines Communication Technology |
analog |
| Work Lead Connector Type |
Dinse |
| Welding Gun Cable Assembly Length |
Magnum PRO 100L |
| Work Cable Length |
10 FT |
| Spool Gun Compatible (Duty) |
Light |
| UI type |
Meters |
| Wire Feeders Processes |
MIG Flux Cored |
| Contact Tips Included |
Yes |
| Sample MIG Wire Included |
Yes |
| Input Voltage |
120/230 |
| Input Current |
120V: 15A, 230V: 15A |
| Input Hertz |
60 |
| Input Power |
120/230/1/60 |
| Input Phase |
1 |
| Mode Icon |
CV |
| Output Range |
120V: 20-140A DC 230V: 20-211A DC Max. OCV : 76V |
| Polarity |
DC |
| Rated Output |
120V: 95A/18.8/60% 230V: 175A/22.8V/30% |
| Typical Application |
Construction Automotive General Fabrication Maintenance & Repair Repair Welding |
| Warranty |
3 Years |
