Millermatic 350P Autobody Package #907300002
This is the first single- or three-phase power Millermatic that welds material from 22 gauge to 1/2 in thick in a single pass. Perfect for fabrication, manufacturing, maintenance and repair.
Included:
- Millermatic 350P power source
- Bernard® Q200 12 ft (3.7m) MIG gun with extra Centerfire™ contact tips
- 8-in. (203 mm), 6-lb. (2.7 kg) spool of Hobart® .047-in (1.2 mm) 5554 aluminum wire
- 10 ft (3 m) work cable with clamp
- 10 ft (3 m) Industrial power cord (without plug) for single- or three-phase
- Factory-installed gas solenoid
- Argon mix regulator/flow meter
- Factory-installed, low-mounted running gear/cylinder rack
- .047 in (0.9/1.2 mm) U-groove drive rolls
- Extra Contact tips
PROCESSES
Flux Cored (FCAW) Pulsed MIG (GMAW-P)
GENERAL SPECIFICATIONS
Industries:
- Auto / Cycle (Racing, Customizing, Restoring)
- Construction
- Manufacturing
- Boat / Yacht
- DIY / Home Hobbyist
- Shipbuilding
- Current Type: DC
- Input Hz: 60 Hz
- Input Phase: 1- and 3-Phase
- Portability: Running Gear / Cart (Standard)
- Net Height: 34 in
- Net Length: 41 in
Input Voltage:
- 208 V
- 220/230/240 V
- 460/480 V
- Max Open Circuit Voltage: 72 VDC
- Net Weight: 181 lbs
Weldable Metals
- Aluminum
- Mild Steel
- Stainless Steel
- Net Width - 19 in
- Warranty - Miller's True Blue Warranty
- Amperage Range - 25 A - 400 A
Material Thickness
- Mild Steel 24 ga - 0.5 in
- Mild Steel 0.8 mm - 13 mm
- Aluminum 14 ga - 0.38 in
- Aluminum 1.2 mm - 13 mm
Wire Feed Speed:
- 1.3 m/min - 17.8 m/min
- 50 IPM - 700 IPM
Wire Diameter Solid Steel
- 0.023 in 0.045 in
Solid Steel
- 0.6 mm 1.2 mm
Stainless
- 0.03 in 0.045 in
- 0.8 mm 1.2 mm
Aluminum
- 0.035 in 0.047 in
- 0.9 mm 1.2 mm
Metal-Core
- 0.035 in 0.052 in
- 0.9 mm 1.3 mm
Flux Cored
- 0.03 in 0.052 in
- 0.8 mm 1.3 mm
Rated Output: 300 Amps at 32 VDC, 60% duty cycle, 1- or 3-Phase
Spool Size: 12 in (305 mm)
For the best prices on Miller welding equipment, all welding machines, and welding helmets, shop Welders Supply online.
Millermatic 350P Specifications |
|||
Input Power |
3-Phase | 1-Phase | |
Amperage Range |
25 - 400 A | ||
Rated Output |
300 A at 32 VDC, 60% duty cycle |
||
Amps Input at Rated Output,60 Hz |
200 V |
34 | 69 |
230 V |
30 | 61 | |
460 V |
15 | 30 | |
KVA |
11.6 | 13.1 | |
KW |
11.5 | 11.2 | |
Wire Feed Speed |
MIG Gun |
50-700 IPM (1.3-18 m/min) |
|
Optional Spool Gunand Push-Pull Gun |
50-800 IPM (1.3-20 m/min) |
||
Wire Type and Diameter |
Solid Steel |
.023 - .045 in. (0.6 - 1.2 mm) | |
Stainless |
.030 - .045 in. (0.8 - 1.2 mm) | ||
Aluminum |
.035 - .047 in. (0.9 - 1.2 mm) | ||
Flux-Cored |
.030 - .045 in. (0.8 - 1.2 mm) | ||
Metal-Cored |
.035 - .052 in. (0.9 - 1.3 mm) | ||
Dimensions |
H: |
34 in (863 mm) | |
W: |
19 in. (483 mm) | ||
D: |
41 in. (1041 mm) | ||
Net Weight |
181 lb. (82 kg) |
SHIPPING DIMENSIONS |
|
Height: | 38.00 Inches |
Width: | 21.00 Inches |
Length: | 42.00 Inches |
Weight: | 215 Lb(s) 0 Oz |
Accessories
Consumables
Product Questions and Answers
Q - What replacement nozzle does the Barnard gun take?
A - #N-5800C, screw-type copper, 5/8-inch (15.9 mm) orifice flush
Q - Is there a cylinder rack for this?
A - Yes, there's a Dual Cylinder Rack, part #195 299
