Miller Bobcat 250 Diesel, GFCI #907565

Part Number: 907565
This product has been replaced by the Miller Bobcat 260 Diesel w/ Remote Start, GFCI 907790.
$9,352.50
$12,169.90* Save $2,817.40
Out of Stock

Welding type:

Mig

Mig

Stick

Stick

Tig

Tig

Engine Driven

Engine Driven

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

  • MIG Welding
  • Stick Welding
  • TIG Welding
  • Engine Driven
  • 3-Year Power Warranty

Miller Bobcat 250 Diesel, GFCI 907565

Rugged welder/generator is great for Stick and Flux-Cored welding and designed for maintenance/repair operations, construction, farm, ranch, and generator use

Smaller and lighter design

New Bobcat welder/generators take up less space on trucks and trailers—leaving more room on your truck for other equipment and tools. Plus, they’re easier to move safely around job sites—even with weld cables and running gear attached.

Accu-Rated™– Not Inflated Generator Power

Miller’s Accu-Rated™ 11,000 watts of usable peak power is delivered for a minimum of 30 seconds. Accu-Rated means peak power is usable for maximum generator loads such as plasma cutting, Millermatic® MIG welders and motor starting. Accu-Rated peak power beats the competition’s very short duration peak or surge power. Use your peak power, it’s more than a number.

Versatile AC and DC Weld Output

Versatile AC and DC weld output provide quality welds on all types of metals. DC is smooth and easy to run while AC Stick is used when arc blow occurs.

Easy Maintenance

With front panel maintenance displays, know when your equipment needs to be serviced.

Front Panel Fuel and Sight Gauges

Front panel fuel and sight gauges provide a convenient fuel level indication. Note: Diesel engine will shut down before the system runs out of fuel making restart easy.
 Browse engine driven welding machines from Welders Supply. Check out our entire selection of welding machinesused welders & equipment and special offers for more deals.

PROCESSES

Air Carbon Arc Cutting and Gouging (CAC-A)
Flux Cored (FCAW)
MIG (GMAW)
Stick (SMAW)
TIG (GTAW)
Plasma (PAC)
Title Bobcat™ 250 Diesel, GFCI
Industries Interests Construction
DIY / Home Hobbyist
Farm and Ranch
Infrastructure
Manufacturing
Maintenance and Repair - Field Operations
Mechanical Contracting
Work / Service Trucks
Engine Brand Kubota
Engine Idle Speed 1800 RPM
Fuel Tank Size 12 Gallon
Fuel Type Diesel
Horsepower 19 hp
Weldable Metals Aluminum
Steel
Stainless Steel
Rated Output 250 A 28 V 100%275 A 25 V 60%
Single Phase Generator Continuous Power 9500 W
Single Phase Generator Peak Power 11000 W
Sound Rating 80 dB @ weld dB
Current Type AC / DC
Amperage Range 40 - 250
Net Width 20 in
Net Height 28 in
Net Length 45.375 in
Net Weight 638 lbs
Warranty Miller's True Blue Warranty
Engine Warranties
Portability Lift Eye (Standard)
Running Gear / Cart (Optional)
Trailer (Optional)
Weld Output CC / CV

SHIPPING DIMENSIONS

Height: 28.00 Inches
Width: 20.00 Inches
Length: 45.38 Inches
Weight: 638 Lb(s) 0 Oz

Product Questions and Answers


Q - What is the warranty on the Bobcat 250 Diesel? A - The Miller Bobcat 250 Diesel has a 3 year manufacturer warranty.
Q - What is the warranty on this? A - 3 years parts and labor. The engine has a 2-year limited warranty by Kubota.
Q - What is the generator power output? A - 11,000 watts peak, 9,500 watts continuous.
