MILLER BOBCAT 250 (KOHLER), GFCI Part#907500

Part Number: 907500
This product has been replaced by the Miller Bobcat 260 GFCI w/ Remote Start 907792.
Out of Stock
$4,951.00 $6,276.16*
SAVE $1,325.16

Call 1-844-682-0205 or CHAT for more options

Welding type:

Mig

Mig

Stick

Stick

Tig

Tig

Engine Driven

Engine Driven

Material type:

Mild Steel

Mild Steel

Stainless Steel

Stainless Steel

Aluminum

Aluminum

  • Multiprocess Welding
  • Smaller & Lighter Design
  • Engine Driven

This product has been replaced by the Miller Bobcat 260 GFCI w/ Remote Start 907792.

MILLER BOBCAT 250 (KOHLER), GFCI Diesel Welder Part#907500

Quieter and Better Sound

Significant improvements in sound level and quality offer better jobsite communication, which provides a safer, more efficient working environment for you and your crew. New Bobcat welder/generators have rotated the engine toward the front to create more efficient airflow, resulting in significantly quieter operation. Now you can start your job earlier in the day and end it later, as well as work around hospitals, businesses, and residential areas.

Smaller and Lighter Design

New Bobcat welder/generators take up less space on trucks and trailers—leaving more room on your truck for other equipment and tools. Plus, they’re easier to move safely around jobsites—even with weld cables and running gear attached.

Smooth Power - Not Spike Power

The revolutionary ten-degree skewed-rotor design optimizes generator performance for smoother power — not spiked power found with other brands. Better power — better performance

Easier Maintenance

With its intuitive design, the daily maintenance of our new Bobcat welder/ generators is faster and easier. With front panel maintenance displays, you know when your equipment needs to be serviced. And servicing is simple because of:

Oil checks that can be performed from the top by the front panel

Toolless panels that allow for quick access

Single-side fuel fill and oil drain/filter

Designed for Reliability

From Appleton, Wis. USA, our welder/generators are the most rugged, durable and long-lasting in the industry. We manufacture them to exceed requirements for extreme working conditions and they are hard-working from the core:

Copper windings and iron generator components for a quality-built machine

Lugged – not soldered – heavy internal leads for better field durability

Superior cooling technology for maximum performance and engine life

Super-tough armor to protect the welder/generator from accidental impact

Protective armor doors to cover the weld studs and receptacles as required by OSHA and CSA

for jobsite safety

Lift hook integrated into the center frame, which bolts to the machine’s base for greater durability

Long runtimes provide many hours of use before refueling is necessary

Accu-Rated™ – Not Inflated Generator Power

Miller’s Accu-Rated™ 11,000 watts of usable peak power is delivered for a minimum of 30 seconds. Accu-Rated means peak power is usable for maximum generator loads such as plasma cutting, Millermatic® MIG welders and motor starting. Accu-Rated peak power beats the competition’s very short duration peak or surge power. Use your peak power; it’s more than a number.

Reversed Generator Airflow

Exclusive engine and generator packaging design operates cooler and more efficiently. The engine is rotated towards the front to create more efficient airflow. More efficient airflow and exclusive engine location are significant contributors to reduced sound level and size reduction. Hot air recirculation is eliminated when machine is mounted in tight spots, and internal parts are kept cool for optimal performance.

Processes

MIG (GMAW)

DC TIG (DC GTAW)

Stick (SMAW)

Flux Cored (FCAW)

Air Plasma Cutting and Gouging (PAC) with Optional Spectrum Models

Air Carbon Arc (CAC-A) Cutting and Gouging

Applications

  • Construction
  • Farm and Ranch
  • Field Maintenance and Repair
  • Stand Alone Generator
View our large selection of MIG, TIG and Stick welders with the greatest values online.

General Specifications

Rated Output

CC/AC Stick/TIG: 225 Amps at 25 Volts
CC/DC Stick/TIG: 250 Amps at 25 Volts
CV/DC MIG/FCAW: 200 Amps at 20 Volts

Welding Amperage Range

CC/AC Stick/TIG: 40 - 250 Amps
CC/DC Stick/TIG: 40 - 250 Amps
CV/DC MIG/FCAW: 17-28 Volts

Net Weight

501 lb (227 kg)

Generator Power 104°F

Accu-Rated Power
11,000 Watts Peak, 9,500 Watts Continuous

Engine

Gas
Kohler CH 23, 23 HP at 3,600 RPM - 3 year warranty

Note: Engines warranted separately by engine manufacturer

Fuel Capacity & Fuel Type

Fuel Capacity
12 gal (45L)

Run Time

  • Welding with an 1/8 inch Stick electrode, 20% Duty Cycle, expect about 20 hours of operation.
  • Under a continuous 4,000 watt generator load, expect approximately 14 hours of run time

SHIPPING DIMENSIONS

Height: 20.00 Inches
Width: 33.00 Inches
Length: 41.00 Inches
Weight: 501 Lb(s) 0 Oz

Product Questions and Answers


Q - I need a spark arrestor to use in a national forest. What part do I need? A - You need the Spark Arrestor (#300924)
Q - What Kohler engine is in it? A - The Kohler CH730. It's a four-cycle gasoline engine with a 12 gallon tank.

How to Transport and Install Generator:

  1. Load Generator.

    Load generator on a flat surface. Do not lift from the end.

  2. Secure Transportation.

    Make sure the generator is attached securely to the truck, trailer, or forklift using straps or.

  3. Find Surface.

    Find flat surface or use cross-supports to support base. Bolt unit down to keep secure.

  4. Other Precautions.

    Do not weld on the base. Do not install where airflow is restricted. Do not support only at the 4 mounting holes.
