Miller Dimension™ 650 380/460 V ArcReach™ 907617001

Part Numbers: 907617001
$9,223.00
$10,653.00* Save $1,430.00

Included with your purchase:

Select your Bundle!
Edit

    Call 1-844-682-0205 or CHAT for more options

    Welding type:

    Mig

    Mig

    Stick

    Stick

    Tig

    Tig

    Material type:

    Mild Steel

    Mild Steel

    Stainless Steel

    Stainless Steel

    Aluminum

    Aluminum

    Power supply:

    220V 3 Phase

    220V 3 Phase

    460V

    460V

    • 3-Year Power Warranty
    • MIG Welding
    • Stick Welding
    • TIG Welding
    • 3 Phase

    Miller Dimension™ 650 380/460 V ArcReach™ 907617001

    Developed for harsh environmental conditions and output requirements that range from power-intensive to precise. ArcReach provides remote control of the power source without a cord – saving time and money.

    Features

    Rugged and Durable Inside and Out - All aluminum construction helps the machine resist corrosion for long life.Exclusive protection input inductor protects machines performance and reliability from “dirty” input power.Wind Tunnel Technology™. Internal air flow that protects electrical components and PC boards from dirt, dust, debris... greatly improving reliability.Fan-On-Demand™ operates only when needed reducing noise, power consumption, and the amount of airborne contaminants pulled through the machine.


    Smaller and lighter - Reduced size and weight results in an easier-to-handle package that exceeds the welding performance of larger, heavier machines. The Dimension 650 uses 40 percent less floor space than previous model.


    Power efficient - High electrical efficiency and excellent power factor mean that you can get more welding done using less power.On 460 VAC, the new Dimension 650 draws only 43 amps at rated load and can operate on a 50-amp service. Four new machines can work at maximum loads simultaneously on a 200-amp service, drawing less amperage than three previous models.

    Improved Arc Performance - High-quality performance from power-intensive to precise.Gouging mode provides 800 amps of usable power, a full 650 amps of power at 100-percent duty cycle. Perfect for heavy gouging with 3/8-inch carbons.Three wire modes (GMAW/FCAW/SAW) for simplified setup and optimized arc performance. Solid and flux-cored wires with gas offer exceptional short-arc MIG precision to weld thin metals with less risk of distortion or burn-through, and premium Flux-Cored welding with gas. Flux-Cored (self-shielded) welding performance is exceptional, especially with wires commonly found in infrastructure construction. Sub Arc mode provides capability to retrofit into nondigital Sub Arc applications. Excellent Stick and Lift Arc TIG performance.Arc control is beneficial when welding with Stick and solid wires for easier fine-tuning of tough-to-weld materials and out-of-position applications.

    See our line of quality welding equipment or view our full selection of quality welding machines and welding machine accessories.

    Processes

    • Air Carbon Arc Cutting and Gouging (CAC-A)
    • Flux Cored (FCAW)
    • MIG (GMAW)
    • Stick (SMAW)
    • Submerged Arc (SAW)
    • TIG (GTAW)

    Miller Dimension™ 650  ArcReach™Specifications:

    Industries Interests Construction
    Fabrication
    Infrastructure
    Heavy Equipment Manufacturing
    Manufacturing
    Railcar
    Shipbuilding
    Carbon Diameter 3/8 ub (9.5 mm)
    Current Type DC
    Input Voltage 380/400 V
    460/480 V
    Input Phase 3-Phase
    Input Hz 50 / 60 Hz
    Max Open Circuit Voltage 87 VDC
    Portability Lift Eye (Standard)
    Running Gear / Cart (Optional)
    Net Height 28.817 in
    Net Length 31.625 in
    Net Weight 158 lbs
    Weldable Metals Aluminum
    Specialty Metals
    Stainless Steel
    Steel
    Net Width 16.687 in
    Warranty 3 Years
    Miller's True Blue Warranty

    SHIPPING DIMENSIONS

    Height: 31.00 Inches
    Width: 21.00 Inches
    Length: 36.00 Inches
    Weight: 165 Lb(s) 0 Oz

    Product Questions and Answers


    Q - Which running gear will work with this? A - The Dimension 650 Running Gear, #301307
    Q - What is the output rating? A - 650 A at 44 VDC, 100% duty cycle
